Grinder
1.Product Introduction
In the conventional processing of brittle materials such as silicon carbide (SiC) and glass, relying on the manual work of craftsmen for processes such as measuring grindstone tools and controlling wear was a major issue. Fortunately, our Grinder offers a solution that automates these processes, improves processing efficiency, and enhances the life and accuracy of grindstone tools.
Designed as a high-precision machining center, our Grinder is suitable for use across a wide variety of industries, from manufacturing and construction to electronics and semiconductors. It uses cutting-edge technology to automate the grinding process, resulting in a level of precision and consistency that would be nearly impossible to achieve with manual labor.
The Grinder is equipped with advanced sensors, which allow it to monitor the condition of the grindstone and make adjustments as necessary, ensuring consistent results every time. It also features a user-friendly interface, which enables operators to easily program the machine for specific grinding tasks and monitor performance in real-time.
For added convenience, we offer a range of customizable options for the Grinder, so it can be tailored to meet your specific needs. Whether you need to grind intricate shapes or large surfaces, our team of experts can help you determine the ideal configuration for your application.
In addition to the Grinder, we also offer the Kailua mold, which is an essential component in the production of high-precision parts. Made from high-quality materials and designed to last, the Kailua mold ensures that your parts are consistent and accurate, so you can maintain the highest levels of product quality.
Overall, our Grinder and Kailua mold provide a comprehensive solution for companies seeking to improve their processing efficiency, enhance their product quality, and reduce costs associated with manual labor. With their advanced features, high precision, and customizable options, they are an investment that is sure to pay dividends for years to come. Contact us today to learn more about how our products can help your business thrive.mer satisfaction makes us an excellent choice for all your molding needs.
2.Classification
| X-Axis | 320mm |
| Y-Axis | 280mm |
| Z-Axis | 300mm |
| Spindle Speed | 400-40000min-1 |
| Fast Forward Speed | 20000 mm / min |
| Cutting Feed Rate | 10000 mm / min |
| Maximum Work Size | 450 x 475 x 200 mm |
| Number of Tool Storage | 15 |
| Maximum Tool Mass | 0.5 kg |
3. Product Feature and Application
About Kaihua Moulds
Founded in 2000 by Daniel Liang, Kaihua has become one of the best injectionplastic mold suppliers in the world, providing services in the design,manufacture, production, and assembly of high-quality tooling.
Kaihua has obtained more than 200 patents.
Through the mastery and flexible use of Mucell, Thin Wall, Gas-Assistance, Steel To Plastic and other lightweight technology, Stack Mould, Low-Pressure Injection Molding, In-Mold Degate , Free Spraying and other high efficiency innovation technology,
Provide customers with the best solutions.
|
Type |
Item |
Advantage |
Customer |
|
Leightweight |
Mucell |
Reduce cycle time,Enhance product accuracy,
Remove sink marks, Reduce clamping force and reduce product weight |
Mercedes-Benz, Volkswagen, |
|
Gas Assistance |
Reduce production cost, Improve appearance |
Land Rover, |
|
|
Thin Wall |
Reduce production cost i.e.raw material cost/Injection production cost by reducing product weight, Enhance product dimensional stability |
Geely, Nissan, Toyota |
|
|
Steel to Plastic |
Reduce product weight, Reduce production cost |
Land Rover, |
|
|
Efficiency |
Stack Mould |
Reduce mould cost and production cost |
Audi, IKEA |
|
Low Pressure |
Improve the qualified rate as well as cladding sense |
Audi, Volkswagen, |
|
|
In-Mold Degate |
Reduce labor cost,enhance production efficiency |
Ford, Land Rover, |
|
|
Free Spraying |
Reduce production cost, Environmentally friendly |
Renault, GM |
Machinery
Injection Production Equipment
■ Krauss Maffei 1600T Three-color Injection Molding Machine
1) Three-color injection molding, Core Back function, DIY main nozzle translation and other functions
2) It can be applied to two-color/three-color injection of headlights, chemical foamed door panels, injection-molded compression spoilers, etc.
■ YIZUMI 3300T Injection Molding Machine with 5 Axis Pickup
■ 17 Injection Molding Machines Covering 160T ~ 4500T
Five-Axis Linkage Mold Processing Equipment
■ FIDIA, Italy
■ MAKINO, Japan
■ DMU, German
■ 12 in Total
■ ……
High Precision Spark Machine
■ DAEHAN
■ MAKINO
■ 7 in Total
MAKINO Automation lines
|
Name |
Function |
Application |
Time Put Into Production |
Quantity |
| FIDIA GTS22 | Five-Axis Linkage CNC | Bumper & Dashboard Overall Processing | Oct. 2019 | 3 Units |
| FIDIA D321 | Five-Axis 3+2 CNC | Bumper & Dashboard Overall Processing | Jan. 2020 | 4 Units |
| MAKINO V90S | Five-Axis Linkage CNC | One-time Molding Of Large Top Block | Nov. 2019 | 2 Units |
| MAKINO F8 | Three Axis High Precision CNC | Medium Die And Part Finishing | Oct. 2019 | 2 Units |
| MAKINO A61nx | Horizontal Four-Axis High-Precision CNC | One-time Molding Of Large Top Block | Nov. 2019 | 1 Unit |
| DMU 90 | Five-Axis Linkage CNC | One-step Molding Of Medium-sized Top Block | Jan. 2020 | 1 Unit |
| DMU 75 | Five-Axis Linkage CNC | Small Top Block Is Formed At One Time | Oct. 2019 | 2 Units |
| DAEHAN Spark Machine |
Four-Head Precision Spark Machine | Dashboard & Bumper Edm Processing | Sep. 2019 | 2 Units |
| DAEHAN Spark Machine |
Double Head Precision Spark Machine | Dashboard & Bumper Edm Processing | Jul. 2019 | 3 Units |
| MAKINO Spark Machine |
Precision Spark Machine | Mirror Edm Processing Of Mesh & Electroplated Parts | Oct. 2019 | 2 Units |
| MAKINO Flexible Graphite Automatic Production Line | Precision Graphite Processing Machine | Graphite Electrode Processing | Oct. 2019 | 6 Units |
Integrated injection molding
From product research and development, mold manufacturing, to injection molding, mass production and assembly, the integration of mold injection molding is realized; the volume of injection molded parts can reach 4m², The molding cycle is short, and the surface quality is high, ensuring "fine molds" to produce "high-quality products".
Strict Quality Control
Implement the project engineer responsibility system, set up a quality control department, and set up an incoming material inspection team, a CMM inspection team, and a shipping and dismantling inspection team. Effectively control quality and progress.
Top Partner
Frequency Asked Questions
Q: Can you do the finished product or parts Only?
A: Sure, We could do finished product according the customized mold. And make the mold also.
Q: Can I test my idea/product before committing to mould tool manufacture?
A: Sure, we can use CAD drawings to make models and prototyping for design and functional evaluations.
Q: Can you do Assemble?
A: Of cause we could do. Our factory with assembly room.
Q: What shall we do if we do not have drawings?
A: Please send your sample to our factory,then we can copy or provide you better solutions. Please send us pictures or drafts with dimensions(Length,Hight,Width),CAD or 3D file will be made for you if placed order.
Q: What type of mould tool do I need?
A: Mould tools can be either single cavity (one part at a time) or multi-cavity (2,4, 8 or 16 parts at a time). Single cavity tools are generally used for small quantities, up to 10,000 parts per year whereas multi-cavity tools are for larger quantities. We can look at your projected annual requirements and recommend which would be best for you.
Q: I have an idea for a new product, but not sure if it can be manufactured. Can you help?
A: Yes! We are always happy to work with potential customers to evaluate the technical feasibility of your idea or design and we can advise on materials, tooling and likely set-up costs.
Welcome your inquires and emails.
All inquires and emails will be replied within 24 hours.
